Borg Warner Turbo S300 S300SX3 66mm 73 T4 Twin Scroll .91 A/R 320-800 HP 177275

BorgWarner Turbocharger SX S300SX3 T4 A/R .91 66mm Inducer

• Twin hydrodynamic journal bearings

• Extended tip technology compressor wheel

• Twin scroll turbine housing options available

• Adjustable compressor and turbine housing orientation

• Compressor cover recirculation grooves

Name S300SX3 S366

Compressor Wheel Inducer 66mm

Wastegated No

Turbo Horsepower Range 250hp - 500hp, 500hp - 750hp, 750hp - 1000hp

Center Cartridge Journal Bearing

Exhaust Housing Inlet T4 Divided Twin Scroll

Exhaust Housing Material Cast Iron

Compressor Housings 4.0" / 3.0"

Exhaust Wheel Exducer 73mm

Exhaust Housing Outlet 3/4 Marmon 4.21"

Exhaust Housing AR .91

Turbo Rotation Standard Rotation
